Obsidiana Volcano PearlTM
THE ETHICAL BEAUTY
polished / Glacé finish
Property | Units of measurament | Quartz Obsidiana |
Fire reaction UNE-EN-ISO 9239-1:2002 & ISO 1716:2002 | Euroclassses | A2fl s1 |
Coefficient of linear thermal expansion UNE EN 14617-11 | ºC-1 | 1,2 x 10-5 |
Flexural strength UNE EN 14617-2 | MPa | 40 – 60 |
Scratch resistance UNE EN 101:1984 | Mohs | 6 |
Impact resistance UNE EN 14617-9 | J | min 2,8 (12 mm) min 5,5 (20 mm) |
Slip resistance UNE EN 14231: 2003 | USRV | Polish: 5 wet / 40 dry Matt: 10 wet / 55 dry |
Abrasion resistance UNE-EN 14617-4 | mm | 29 – 32 |
Water absorption UNE EN 14617-1 | % | 0,04 – 0,06 |
Apparent density UNE EN 14617-1 | g/cm3 | 2250 – 2350 |
Chemical resistance UNE EN 14617-10 | C4 | C4 (material keeps at least 80 % of the reflection reference value after 8h of basic attack) |
The values in this data sheet are only typical values and not vinculant. For more information or test reports please contact our quality department.
Technical specifications
Application
Application
Sizes
Quality Certificates
Cradle to Cradle Certified™ Bronze, a certificate that guarantees the sustainable characteristics of this innovative material created from 100% recycled glass. An international recognition that evaluates the products and their manufacturing process to ensure that the premises of the circular economy are met. | |
IQ Circular Science, the responsible sense of COMPAC, the philosophy of respect for the environment that we have been working on for years. All of our portfolio designs are produced sustainably with 100% renewable energy and 98% of the water used in the production process is recycled. In addition, IQ Circular Pro includes recycled raw materials. Similarly, all designs contain little or no Respirable Crystalline Silica (RCS). | |
HPD CERTIFICATE. Health Product Declaration® (HPD) Collaborative is an association representing the full spectrum of the building industry which certificates improvements in product information transparency and material health in buildings and the environment. | |
Environmental Product Declarations (EPDs). Environmental Product Declarations (EPDs) present relevant and verified environmental information on products and services over their entire life cycle. |
Quality Certificates
Technical documents
- Obsidiana Catalog 2024 Download
- Countertop Design and Installation Manual 2022 Download
- Technical recommendations for laying Download
- Warranty 2022 Download
- Declaration of Performance 2022 Family 1: Volcano Cloud, Volcano Dark, Volcano Fog, Vocano Light, Volcano Grey, Volcano Pearl Download
- Cleaning, conservation and maintenance manual OBSIDIANA Download
Technical documents
